AIDA GEN3G-IPC-200 FHD Genlock 3G-SDI/HDMI With IP Control POV Camera

AIDA GEN3G-IPC-200 FHD Genlock 3G-SDI/HDMI with IP Control POV Camera

The GEN3G-200 was AIDA’s first staple into the broadcasting world, and now they have come with a successor ! The GEN3G-IPC-200 brings everything you love from the GEN3G-200, with a refreshed Sony CMOS sensor, camera control via VISCA over IP, and your favorite way to sync to directly to any Tri-Level Sync Generator like our TGEN-6P. Continue the legacy by staying locked IN at all times with this new and improved camera!

KEY FEATURES

• Full HD Progressive Scan sensor captures sharp and vivid color under
  different light conditions.
• Advanced digital image processor provides vivid and detailed images
  by utilizing WDR, White Balance, and Noise Reduction.
• Motion-compensated temporal noise reduction filter leads to effective
  noise reduction for motion video without blur.
• Tri level sync Gen-lock synchronizes GEN3G cameras and other system
  components for seamless vertical interval switching between sources.
• 3G/HD-SDI & HDMI seamless video performance.
• Compatible with other industry leading products, conforming with
  SMPTE 424M/292M standard.
• Self-Adaptive Resolution Feature captures your reference
  feed instantly.
• Black Level Set-up provides the better color transition from digital
  to analog.
• VISCA over IP enabled to allow for easier communication over ethernet wire,
  as well as traditional RS485 communication.
• Interchangeable lens design makes it compatible with auto-iris CS
  and C mount lenses.
• Flawlessly relays embedded audio via SDI & HDMI.
• Controllable camera parameters through our free AIDA IPC Program.
• Versatile, compact, and rugged design.

SPECIFICATIONS AIDA GEN3G-200 3G-SDI / HDMI Full HD Genlock Camera

Image Sensor	1/2.8 inch Progressive CMOS
Sensor Size	5.641mm x 3.216mm (16:9)
Effective Pixels	Horizontal: 1920, Vertical: 1080
Pixel Size	2.9 μm (H) x 2.9 μm (V)
Resolution	1080p & 1080i: 1920 x 1080 720p & 720i: 1280 x 720
Resolution/Rate	1080p 60/59.94/50/30/29.97/25/24/23 fps 1080p 60/59.94/50 fps 720p 60/59.94/50 fps
Output	HD-SDI/3G-SDI (1BNC), HDMI 1.3a
Color Space	4:2:2 (YCbCr) 10bit
Min. Illumination	0.2Lux (Day), 0.1Lux (Night), 0.005Lux (Slow Shutter ON)
White Balance	Auto & Manual (9,000 K – 11,000 K)



Lens

Lens	C/CS Mount (Default 4mm HD Lens)

Audio

Audio Input	3.5mm Line Input through I/O cable
Sample Rate	16/24/32 Bits



Standard

SMPTE

SMPTE 292M, SMPTE 424M



Synchronization

Genlock

External Tri-Level Input (IN / OUT)



Physical

Camera Control	RS-485, OSD Button
Operation Temp	32° F – 104° F
Dimension	88.90mm x 44.45mm x 44.45mm / 3.50” x 1.75” x 1.75” (With default 4mmLens)
Weight	170g / 0.37lbs (With default 4mm Lens)
Power	12VDC (+9 – +15VDC) (PoE+ injector possible)

INCLUDED BY DEFAULT

• AIDA GEN3G-IPC-200
• I/O Breakout Cable
• 4mm Megapixels Lens(Pre-Installed)
• DC 12v Power Supply & Sockets Adapter
• C-Mount Cap Adapter
• Sensor Cap
• PoE Dongle Adapter
