Name: Stijlvol en Duurzaam: Winkel de Atomos Sumo 19 SE Collectie in Nederland.
SKU: AT-ATOMSUMO19SE
Price: 96.99 EUR
Availability: InStock

Aanbieding!

Oorspronkelijke prijs was: 319,00 €.Huidige prijs is: 96,99 €.

The Atomos Sumo 19″ SE HDR Monitor, Recorder, and Switcher has been upgraded with an 19″ 1920 x 1080 QLED touchscreen display and 1200 cd/m² brightness. It still maintains the same 4K recording, monitoring, and switching capabilities of its predecessor with a sharper and brighter display.

Artikelnummer: AT-ATOMSUMO19SE Categorieën: On Camera / Field Monitors, Studio & EFP Equipment

Koop met een gerust hart
Koop online de beste kwaliteit
Winkel met gemak
Risicovrij winkelen met retouren

Atomos Sumo 19 SE Monitor Recorder Switcher

The Atomos Sumo 19″ SE HDR / High Brightness Monitor Recorder / Switcher can be implemented to enhance professional video workflows in both production and post-production with its large, bright color-accurate 19″ QLED screen and 4K recording capabilities. On set, the Sumo’s HDR capabilities enable cinematographers to realize more of a cinema camera’s dynamic range when shooting in log or raw formats.

With a bright (1200nit), HDR touchscreen covering the DCI-P3 (P3) Color Gamut, the ability to record Apple ProResRAW up to 6Kp30, and a rugged and versatile design, the SUMO 19SE is the perfect addition to an on-set video village. With four independent inputs it can also be used to switch and record each ISO stream up to 1080p60 and has full-sized XLR connectors for professional audio workflows. Unlock the true potential of SDI RAW cinema cameras with the Sumo 19SE. Preserve the pristine quality of the data from the camera sensor by recording in Apple ProRes RAW at up to 6Kp30, 4Kp60 DCI/UHD, and 2Kp240 DCI/HD, or record in CinemaDNG at up to 4Kp30 DCI. Sumo 19SE is compatible with the Sony FS series cameras, Canon C300MKII/C500, Panasonic EVA-1/Varicam LT, and more.

Video from any camera or digital video source can be captured via SDI or HDMI. Record up to 10-bit 4:2:2 in Apple ProRes or Avid DNxHR codecs at 4Kp60. With support for multiple inputs via SDI, the SUMO 19SE provides the ability to record up to 4 x inputs and also supports ProRes LT and DNxHD 36 for extended recording times.

KEY FEATURES

1920 x 1080 QLED Touchscreen Display
HDMI 2.0 & 12G-SDI Inputs/Outputs
Quad-HD Live Switching & 5-Ch Recording
1200 cd/m² (±10%) Brightness
ProRes RAW Support
8-Bit+FRC 422 ProRes/DNxHR Encoding
HDR Mode with 10-Stop Dynamic Range
Two XLR Inputs with +48V

SE Upgrades and Features

Upgraded 19″ Quantum Dot OLED display with 1200 cd/m² brightness (±10%)
Live, quad-channel HD switching and recording
Supports recording in ProRes RAW and 10-bit 422 ProRes/DNxHR
HDMI 2.0 and quad-SDI support genlock and LTC timecode
Works in HLG and PQ formats of HDR

Live Quad-Channel HD Switching and Recording

Record four streams simultaneously as separate ISOs while cueing and switching in real time
Record fifth channel of switched feel and display resulting in mixed output live on set (via HDMI or SDI)
Switching is asynchronous and can be output with Atomos Connect 4K

HDR Capabilities

10-bit processing takes RAW/Log/PQ/HLG output from camera or gaming consoles
Maps to display 10+ stops of dynamic range in real time

Two XLR Inputs with Phantom Power

Full-size XLR connections with +48 phantom power
Connect two external microphones for balanced analog audio recording and monitoring
Dedicated meters, gain controls, and adjustments for frame delay on each channel
Mic or line level audio can be synced with embedded HDMI and SDI audio

Powering the SE

Dual 4-pin XLR inputs for continuous dual battery power
Includes BattWing mounting bracket for integration of V-mount or Gold mount battery 95Wh or larger
Includes AC power supply, 12-16.8V DC input

SPECIFICATIONS ATOMOS SUMO 19 SE MONITOR RECORDER SWITCHER

Physical Specifications
Dimensions (W x H x D mm)	310mm / 12.2″ x 504 mm / 19.8″ x 63mm / 2.5″
Weight	6.2kg / 13.7lb
Mount points	Top: 4 x 1/4′ 20, 2 x 3/8″, Bottom: 6 x 1/4′ 20, 3 x 3/8″ Right: 4 x 1/4′ 20, 2 x 3/8″, Left: 2 x 1/4′ 20, 1 x 3/8″
VESA mount	100 x 100
Environmental
Ambient operating temperature	Up to 40 Degrees Celsius
Construction and Control
Cooling	Actively controlled fan and Heat Sink
Tally light	Rear and front
Multi-function button	Power / lock Screen
Touch Screen	Yes
Power
Input voltage	DC 12-16.8v
Operating power	75W
Compatible batteries	V-Lock / Anton Bauer Gold Mount via XLR terminal, (optional mounting plates available), 95Wh+ recommended.
Battery voltage	14.4V nominal
Battery Run time (Record)	Depends on Watt Hours specification of battery used
Battery Run time (Monitor only)	Depends on Watt Hours specification of battery used
Continuous power	Dual Battery input via dedicated 4 pin XLR
DC in connector	1 x 4 pin XLR (12-16.8V)
Dtap	Via optional D-Tap to 4 Pin XLR cable.
Display
Touchscreen	SuperAtom IPS panel (capacitive touch)
Size	19″
Resolution	1920 x 1080
PPI	120
Bit depth	10Bit (8+2 FRC)
Backlight Type	Optically bonded quantum dot
Brightness (cdm2 / nits)	1200nit (+/- 10% @ center)
Aspect ratio	16:9 Image Display
De-interlace mode	Yes
Color Gamut	DCI P3
Calibration support	Atomos Calibrator with Calibrite ColorChecker Display Pro or ColorChecker Display Plus
Color Pipeline
Gamma	Sony SLog / SLog2 / SLog3, Canon CLog / CLog2 / Clog3, Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 /LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic V-log, JVC JLog1, Red LogFilm / Log3G10 / Log3G12, FujiFilm F log, PQ (HDR10), HLG, Nikon N-Log
Gamut	BT2020, DCI P3, DCI P3+, DCI p3 65, Sony SGamut / SGamut3 / SGamut3.cine, Canon Cinema, Panasonic V Gamut, Arri Alexa Wide Gamut, Rec709, JVC LS300, F-Gamut, Red DragonColor / DragonColor2 / RedColor2 / RedColor3 / RedColor4 / RedWideGamut
3D LUT Display	.Cube format
3D LUT Output	Loop out
3DLUT 50/50	Yes
Monitoring Modes	Native/ 709 / HLG / PQ / 3D LUT
HDR output Conversion	HDR to HLG / PQ
Color Management
Calibration	Atomos Calibrator with Calibrite ColorChecker Display Pro or ColorChecker Display Plus
Display Controls	Backlight, Lift, Gamma, Gain
AtomHDR	Built in Technical Log to HDR EOTF
3D LUTs	Display, monitor and output, Record, Load via SSD
Legalize	Full to Legal conversion available on Input
Video Input
HDMI	1 x HDMI (2.0) 4K p60
HDMI RAW	No – HDMI Video only
SDI	4 x 3G SDI, with 2 x 12G SDI backwards compatible, auto detection
SDI RAW	Apple ProRes RAW up to 6Kp30
Bit Depth	8/10Bit Video / RAW up to 12Bit
Video Chroma Subsampling	YCbCr 422
HDR	Yes with Auto detection
Metadata
SDI	File Name from Arri, RED. RAW – white balance, Exposure index, Shutter speed/angle, Iris F stop, ISO, Gamma, gamut
File Naming
Standard	S/S/T & Rolling
Via SDI	Red, Arri
Video Output
HDMI	1 x HDMI (2.0) 4K p60
SDI loop out	1 x 12G SDI Backwards compatible, Auto detection. Level A and B selectable
SDI Play out	1 x 12G SDI Backwards compatible, Auto detection. Level A and B selectable
Video Chroma Subsampling	422
Bit Depth	10Bit Video / 12Bit RAW
Web Streaming
USB UVC	Optional via ZATO Connect / USB Stick
Video Signal Conversion
HDMI to SDI	Yes
SDI to HDMI	Yes – Video and RAW
Audio In/Out
Audio Quality	24-Bit / 48kHz
Audio Codec	PCM
HDMI	8ch 24Bit, input dependent
SDI	12ch 24Bit, input dependent
Analogue Audio in	2 x XLR
Analogue Audio Out	2 x XLR
Speakers	2 x 5w
Headphone out	3.5mm 2ch.
Timecode / Sync
Embedded	SDI and HDMI
Time of day	Yes, Time and Date
LTC	LTC via BNC input in Record mode
Genlock	Genlock in Playback mode
Resolution and Frame Rates (Record, Monitor & Playback)
4k DCI	up to 4Kp60
4k UHD	up to 4Kp60
2K DCI 2046 x 1080	up to 2Kp60
FHD 1920 x 1080 Progressive	up to 1080p120
FHD 1920 x 1080 PsF	Pull down
FHD 1920 x 1080 Interlaced	1080i50 / 1080i60
1280 x 720p	60p
6K RAW	up to 6Kp30 Via SDI
4K RAW	up to 4Kp60 via SDI
2K RAW	up to 2Kp240 via SDI
Recording CODEC
CDNG	For SDI RAW inputs Only
Apple ProRes RAW	ProRes RAW, ProRes RAW HQ up to 12bit 6Kp30 / 4Kp60
Apple ProRes	Apple ProRes HQ / 422 / LT up to 4Kp60
Avid DNxHD	up to 1080p60
Avid DNxHR	up to 4Kp60
Playback
Playlist	Yes, Create custom play lists from full or sub clips
Loop	Yes, with user customizable in / out markers
CDNG	No
Apple ProRes Raw	Yes, recorded clips with linear PCM
Apple ProRes	HQ / 422 / LT – Yes with linear PCM
Avid DNx	DNxHR / DNxHD – Yes with linear PCM
Monitoring
SDR	Native, 709, LUT
HDR	HLG, PQ Rec2020
De-Interlace	Selectable mode
Recording functions
Pre-roll record	Yes (HD 8s, 4K 2s) – Not available in RAW
ISO Record	4 x ISO up to 1080p 60 (3G SDI Level A ONLY)
Switched Program Record	Yes Up to 1080p 60
Timelapse	Yes
Multi Input / Switching
SDI A/B toggle	Yes, supports up to 12G SDI per input
Dual Input display	Via Multi ISO input mode
Multiple SDI input	Up to 4 x up to 1080p 60 (3G SDI Level A ONLY)
Multiview Display	Via Multi ISO input mode
Input transitions	Auto or manual XML transition
Input Switching	Yes
Supported media
Master Caddy I	No
SSDmini	Yes (AtomX SSDmini handle required)
CFast II	Not supported
File System	ExFAT
Interface	SATA 3
Master Caddy III	Yes
On screen tools
Waveform	3 sizes
RGB parade	3 sizes
Vector scope	2 size / Position
1 x Zoom	Yes. 1:1 Pixel mapping for 4K
2 x Zoom	Yes
Focus peaking	Colour selected / threshold setting / colour/ Mono / edges only
False colour	Yes, with IRE scale
Zebra	Yes, customisable
Isolate color channel	Blue only
Cine Frame Guides	2.4:1, 2.35:1, 1.9:1, 1.85:1, 4:3
Social Frame guides	9:16, 1:1, 1.91:1, 4:5
Safe areas	SMPTE frame size – Action and Safe
Grid markers	9 grid
Anamorphic desqueeze	Display 1.25x, 1.33x, 1.5x, 1.8x and 2x
Display Flip	Vertical
False Color	Yes, with IRE scale
Onboard Signal Processing
4K UHD Downscale for HD	Loop out – 4K UHD to FHD
DCI Crop	Loop out – 17:9 to 16:9 Crop
I > P	60i > 24p (3:2 pulldown)
PSF > P	24/25/30pSF > 24/25/30p (2:2 pulldown)
Remote control
HDMI	Auto HDMI Trigger, Supported Protocols – Canon, Sony, Atomos Open Standard
SDI	SDI trigger, camera selectable
Serial 2.5mm Jack	LANC control and calibration via optional USB to serial cable
Cut & Tag
FCP XML	Cut tag EDL and Multicam with transitions in FCP XML
Supported Applications
XML	Apple Final Cut Pro
Apple ProRes RAW	Apple Final Cut Pro, Adobe Premiere, Avid Media Composer, Grass Valley Edius, ASSIMILATE SCRATCH
Video Codecs	All applications with support for Apple ProRes and Avid DNX in .MOV wrapper
What’s in the box
Accessories included	SUMO 19SE unit, 1x Master Caddy II, 1x BattWing mounting bracket with 4x screws, 2x Desktop Feet with 4x 1/4” Mounting screws, AC power supply
Optional extras	Sunhood, UltraSync One, HDMI cables, USB to serial cable
Warranty
Standard	1 Year
Extended	3 Years
Target use / User
Cinema	Yes
Director Monitor	Yes
Mixer/Swircher/ProAV	Yes
Rack/OB	Yes
DIT/Video Village	Yes
Pro Video	Yes
Editor/Colorist	Yes
