AVMATRIX MMV1630 16CH 3G-SDI Multiviewer & Switcher

AVMATRIX MMV1630 16CH SDI Multiviewer & Switcher

The AVMatrix MMV1630 16CH SDI Multiviewer & Switcher is the perfect solution for a advanced broadcast project. The MMV1630 is a multifunctional with a built-in 16 channel SDI multiviewer and 16×16 SDI matrix switcher. The input signal automatically detects SD, HD and 3G-SDI. The video format of the multiview output are 9 formats in total from 720p to 1080p. In addition, 20 standard layouts with 16/12/11/10/9/8/6/4 preset are supported. It is also possible to view any input signal in full screen through the shortcut key. MMV16310 also supports UMD, audio meter, signal status and time code overlay. All functions can be quickly controlled by the PC software or front panel button & knob.

KEY FEATURES AVMATRIX MMV1630

SPECIFICATIONS AVMATRIX MMV1630

Model	MMV1630
Multiviewer Mode	Inputs	16 x SD/HD/3G-SDI
	Loop outputs	16 x SD/HD/3G-SDI
	Outputs	2 x SDI 1 x HDMI
	SDI input formats	1920 x 1080p at 60/59.94/50/30/29.97/25/24/23.98 Hz 1920 x 1080PsF at 30/29.97/25/24/23.98 Hz 1920 x 1080i at 60/59.94/50 Hz 1280 x 720p at 60/59.94/50/30/29.97/25/24/23.98 Hz 625i 50 PAL 525i 59.94 NTSC
	SDI/HDMI output formats	1080p at 60/50/30/25/24 Hz 1080i at 60/50 Hz 720p at 60/50 Hz
	SDI Auto Switching	Auto Selects SD, HD, and 3G-SDI on Input
	SDI Video Rate	SD/HD/3G-SDI
	SDI Compliance	SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M
	Color Space	YUV 4:2:2, YUV 4:4:4, RGB 4:4:4 (SDI Input) YUV 4:2:2 (Multiview HDMI/SDI Output)
Switcher Mode	Inputs	16 x SD/HD/3G-SDI/DVB-ASI
	Outputs	16 x SD/HD/3G-SDI/DVB-ASI
	SDI input formats	2048 x 1080p at 30/29.97/25/24/23.98 Hz 2048 x 1080PsF at 30/29.97/25/24/23.98 Hz 1920 x 1080p at 60/59.94/50/30/29.97/25/24/23.98 Hz 1920 x 1080PsF at 30/29.97/25/24/23.98 Hz 1920 x 1080i at 60/59.94/50 Hz 1280 x 720p at 60/59.94/50/30/29.97/25/24/23.98 Hz 625i 50 PAL 525i 59.94 NTSC
	SDI Auto Switching	Auto Selects SD, HD, and 3G-SDI on Input
	SDI Video Rate	SD/HD/3G-SDI
	SDI Compliance	SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 352M, SMPTE 372M, SMPTE 424M, SMPTE 425M, DVB-ASI
	Color Space	YUV 4:2:2, YUV 4:4:4, RGB 4:4:4, XYZ 4:4:4
Controls	Control	Front Panel Buttons and Knob
Power	Power Connector	Threaded Locking connector
	Voltage Range	12 to 20 VDC
	Power Supply	PS-1, PS-2, Power Redundancy
	Power Consumption	36W
Environment	Operating Temperature	0 to 60°C
	Storage Temperature	-30 to 70°C
	Relative Humidity	0 to 90%
Size	Size	Standard 19” Rack unit
	Weight	2KG
	Dimensions	48.3 x 4.4 x 14.9 cm
Warranty		3 Years

DIMENSIONS



INCLUDED BY DEFAULT

• MMV1630 16CH SDI Mutltivewer & Switcher
• 2x DC 12V 5A Power Adapter
