Blackmagic Design Mini Converter SDI To Audio

Blackmagic Design Mini Converter SDI to Audio

The Blackmagic Design Mini Converter SDI to Audio is the perfect way to de‑embed audio from any SDI source in SD and HD formats up to 1080p60! Audio is output on ¼” connectors for balanced analog and AES/EBU audio output to equipment such as mixers, analog decks, audio monitors and more. Mini Converter SDI to Audio is the ideal SD/HD SDI audio de‑embedder for when you don’t need the cost of the Ultra HD model!

KEY FEATURES

SDI Video Inputs

• 1 x SD, HD or 3G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.

SDI Video Outputs

• 1 x SDI Loop Output.

Analog Audio Outputs

• 4 channels of professional balanced analog audio.

Digital Audio Outputs

• 8 channels of professional balanced AES/EBU audio.

SDI Redundant Inputs

• Automatically switches over if main SDI input is lost.

Multi Rate Support

• Auto detection of SD, HD or 3G‑SDI.

Updates and Configuration

• Via USB 2.0 high speed. (480 Mb/s)

Reclocking

• Yes

SPECIFICATIONS Blackmagic Design Mini Converter SDI to Audio

Model	CONVMCSAUD
SDI Input	SDI: Switchable between SD, HD and 3 Gb/s SDI SDI Redundant: Automatically switches over if main SDI input is lost
Analog Audio	4 channels of professional balanced analog audio with standard 1/4 inch jack connections
AES/EBU	8 channels of professional balanced digital with standard 1/4 inch jack connections
Format	625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60
Sampling	4:2:2
Power Requirements	12VDC (includes power supply)

INCLUDED BY DEFAULT

• Mini Converter SDI to Audio
• 12V universal power supply with international socket adapters
