EVERET EVP230N – FHD NDI|HX2 PTZ Camera PoE 30x Zoom

Everet EVP230N FHD NDI|HX2 PTZ Camera with 30x zoom

The Everet EVP230N FHD NDI PTZ camera with 30x zoom is a professional grade Full HD video camera with NDI|HX 2, HDMI, 3G-SDI, IP output interface and 3.5 mm Audio Input. Simplifying setup for live streaming systems supporting PoE, high quality video, tally and control using a standard gigabit enabled network and native integration of industry standard video software including Wirecast, xSplit, OBS, vMix, Livestream studio, Tricaster and more. With the high quality optical lens, 30x optical zoom, 0.1 lux and low latency, ideal for live streaming, events, house of worship and education. Everet PTZ cameras are Black Magic ATEM Television Studio Compatible.

KEY FEATURES

• Advanced ISP, high quality 1/1.7 inch 12MP Sony sensor
• High Quality Full HD lens with 30x Optical Zoom + 2x Digital Zoom, with 60 degree field of view
• NDI|HX 2, 3G-SDI, HDMI output video simultaneously
• IP Video Streaming, includes both H.264, H.265 video encoding
• 3G-SDI compatible with Blackmagic Design ATEM (e.g. 1080p50/1080p60)
• WDR, 3D Noise Reduction feature
• Power over Ethernet (PoE) support: get video, control, tally and power supply with one CAT5/6 cable
• Image Flip function, up to 128 user defined presets, built-in tally light
• Special Focusing Algorithm: fast and precise focusing performance when zooming or moving
• IP, HDMI, 3G-SDI outputs
• 3.5mm Audio Input
• Whisper quiet PTZ design, accurate pan tilt motor control
• Standard IP VISCA, Serial VISCA, PELCO-P/D control protocol; IP VISCA over TCP/
• Supported vMix PTZ NDI Camera

SPECIFICATIONS EVERET EVP230N NDI PTZ CAMERA

Model Number	EVP230N
Sensor	1/1.7 inch, 12 MP high quality Sony CMOS sensor
Video Format	HDMI	NDI|HX 2	3G-SDI
	1920*1080p60/59.94/50/30/29.97/25/24 1920*1080i60/59.94/50, 1280*720p60/59.94/50/30/29.97/25	Main stream 1920*1080@30, Sub stream: 1280*720@30 1024*576@30 640*360@30	1920*1080p60/59.94/50/30/29.97/25/24 1920*1080i60/59.94/50, 1280*720p60/59.94/50/29.97/30/25
Zoom	30x optical zoom + 2x digital zoom
FOV	2.02° (near) ~ 60° (far)
Min. Focus Distance	Wide: 0.3m               Tele: 1.5m
Preset	10 via remote controller; 128 via serial port; preset precision:0.1°
Rotation Angle	Pan: -170° ~ +170°; Tilt: -30° ~ +90°
Rotation Speed	Pan: 0°~120°/s; Tilt: -0°~80°/s
Control Port	`NDI|HX / RS232 / RS485 / RJ45
Video Port	HDMI / RJ45 NDI|HX 2 / SDI
Noise Reduction	2D&3D
SNR	>50dB
Focal Length	f＝5.8(near)～203mm(far)
Minimum LUX	0.1 LUX
White Balance	Auto / Manual / Auto Tracking / OnePush / Indoor / Outdoor
Anti Flicker	50Hz/60Hz/OFF
D/N Mode	Supported
Gamma	Supported
Mirror Image	Supported
Image Flip	Supported
Iris	Auto / Manual
Shutter Speed	Auto / Manual
Backlight Compensation	Auto / Manual
Focus	Auto / Manual
Video Encoding	H.264/H.265
Bit Rate Control	Variable Bit Rate, Constant Bit Rate
Video Bit Rate	1024Kbps~20480Kbps
Frames	50HZ:1fps~50fps  60HZ:1fps~60fps  （3840×2160 max. 30fps）
Protocol	TCP/IP, HTTP, RTSP, RTMP, ONVIF, DHCP, VISCA over IP (TCP&UDP), HTML5
POE	Supported
Input Voltage	DC12V/12W/2A PoE+ recommended (IEEE802.3at)
Dimensions	220mm×173mm×190mm
Net Weight	1.25KGS（2.8LBS）

INCLUDED BY DEFAULT

• EVERET EVP230N NDI PTZ Camera
• DC12V Power Adapter
• Power Cable
• RS232 Cable
• IR Remote Controller
