Kiloview G2 HDMI SRT H.264 4G Wireless Video Encoder

Kiloview G2 HDMI SRT H.264 4G/Wifi Video Encoder

The Kiloview HDMI to H.264 SRT Wi-Fi Video Encoder is a HDMI H.264 video encoder that supports HDMI 1.4 standard compatible signal input, and HDMI looping. It has a built-in dual-band (2.4G/5G) Wi-Fi and supports a 10/100M self-adaptive Ethernet interface. This encoder supports unbind audio from HDMI signal as well as input audio from analog line-in. It features a microSD/TF card slot and USB Type-A and mini-USB ports for storage. Multi-language is supported for worldwide users. Two Wi-Fi dual-band antennas and a 12 VDC power adapter are included.

KEY FEATURES

• H.264 video encoding
• SRT
• Full HD Live streaming
• Support wifi/4g/Ethernet
• Dual streams output supported
• Low bandwith (1Mbps@720p, 1.5Mbps@1080p)
• Low latency( ≤ 67
• HDMI Loop-through for live monitoring
• Low power consumption (<4w)
• Portable
• Manage with Android app or via web app
• Built-In IEEE 802.11 a/b/g/n Wi-Fi
• HDMI Input/Output
• 3.5mm Analog Audio Input & Output
• RJ45 Ethernet Port
• Micro SD/TF Card Slot
• USB Type-A & Mini-USB Ports for Storage
• Two Wi-Fi Antennas
• 12 VDC Power Adapter
• ONVIF Compliant

SPECIFICATIONS KILOVIEW G2 HDMI SRT H.264 4G/Wifi Video Encoder

Video input	HDMI
Video loopout	HDMI
Analog audio input	3.5mm
Analog audio output	3.5mm
USB interface	2*USB  2.0 Type-A; 1*USB 2.0 Mini-USB
Micro  SD	Micro  SD/TF  Card
Video resolution	1080p23.98/24/25/29.97/30Hz 1080p50/59.94/60Hz 1080i50/59.94/60Hz 720p23.98/24/25/29.97/30Hz 720p50/59.94/60Hz, 576i, 480i 720*480(NTSC)，720*576(PAL)
Transmission mode	4G-LTE、WiFi 、Ethernet
Video Encoding	H.264/AVC High profile
Audio encoding	AAC/G.711
Encoding latency	≤67ms
Streaming media protocols	SRT/RTMP/HLS/TS over UDP/RTP/RTSP
Management	Android App or Web
Power	DC 12V 1A
Operating temperature	-4°F to 160°F /-20℃ to 6℃
Dimensions	4.9 x 3.5 x 1.125″/125*89*28mm
Weight	13.4oz /380g

INCLUDED BY DEFAULT

• Kiloview G2
• Antennas
• Power adapter
• Quickstart Guide
