Kiloview N2 Portable Wireless HDMI To NDI Video Encoder

Kiloview N2 NDI – Wireless HDMI to NDI Video Encoder with battery

NDI has become a more convenient and reliable video transmission technology which is widely applied in the video production process. The Kiloview N2 video encoder can directly convert a HDMI video signal into NDI, and realize ultra-low-latency transmission through WIFI (or wired Ethernet) to various other NDI compatible devices or software like vMix on the same network.

The portable unit inputs HDMI video up to 1080p60 and outputs the signal over Wi-Fi, or by Ethernet using the included USB expansion adapter, for use in your streaming NDI video workflow. It supports NDI-HX/RTMP/RTSP/SRT/HLS/TS over UDP streaming media protocols and H.264/AVC/MJPEG compression, allowing it to work with a variety of platforms with very-low latency.

The N2 encodes embedded audio in ACC or G.711 format, and it also supports voice intercom audio. It also features a TF/microSD card slot to record video while you are streaming, or it can be configured to record to a NAS over a LAN. Recording formats include TS, MP4, MKV, AVI, and MOV. It can be controlled and configured using an Android app, via a web GUI, or by using an IMS remote management application. A second USB port also allows you to control the unit via serial control using a separately available USB to serial adapter.

The unit is powered using its internal 6800mAh battery, so you can avoid cabling while it’s in use. There are two mounting threads on the bottom and a shoe mount with removable shoe adapter are included to mount onto any standard shoe mount. Two RP-SMA Wi-Fi antennas are included to ensure signal strength, and a power adapter is included to charge the battery.

KEY FEATURES

• HDMI to NDI Video Converter
• Supports up to 1080p60 Video
• Portable Form Factor, Lossless Quality
• Enabled with Wi-Fi & USB/Wired Ethernet
• Built-In Battery, Shoe Adapter & Mount
• SD Card Recording to TS/MP4/MKV/AVI/MOV
• Voice Intercom Support
• Antennas & USB-to-RJ45 Adapter Included
• Optional Serial Control via USB
• Dual stream output (also through RTMP) and Local recording

SPECIFICATIONS KILOVIEW N2 PORTABLE WIRELESS HDMI TO NDI VIDEO ENCODER

Model	Kiloview N2
Input	1 x HDMI
Transmission mode	Enhanced WIFI（Enhance 5G frequency+PA）、USB expansion cable
Media protocol	NDI-HX
Resolution	Up to 1080P60Hz： 1080p23.98/24/25/29.97/30; 1080p50/59.94/60; 1080i50/59.94/60; 720p23.98/24/25/29.97/30; 720p50/59.94/60
Video encoding	H264/AVC, Motion-JPEG
Audio encoding	AAC/G.711
Delay	End-to-end of cable is about 150 ms
Graphic overlay	Support custom text, image overlay function, can be superimposed to any position on the screen
Voice intercom	Supported (required a voice intercom software)
Recording	SD/TF card slot, local recording, NAS network storage
Management	Web, APP
Hot shoe	Removable
Battery capacity	3.7V 6800mAh（29.6Wh）
Power supply	DC 12V 1A
Power consumption	6.5w
Operating temperature	-20℃~45℃
Dimension	115*75*35mm(4.53*2.95*1.38in)
Weight	380g(13.4oz)

INCLUDED BY DEFAULT

• Kiloview N2 Portable Wireless HDMI to NDI Video Encoder
• Hot-shoe mount
• Antennas
• Ethernet USB extension adapter
• Power Adapter
