Lumantek Ez-CGER Mini Live HD-SDI USB Fill/Key And CG Generator With CGER Software

Lumantek ez-CGER Mini Live HD-SDI USB Fill/Key and CG Generator with CGER Software

The Lumantek ez-CGER Live HD-SDI USB Fill/Key and CG Generator is a simple and small HD live graphic system for live conferences and active video presentations. Create and present on-screen CG and texts in real-time using the generator and CGER software via the USB 3.0 port, and generate Fill/Key signals to the HD-SDI port.

KEY FEATURES

• USB 3.0 Input
• Fill/Key SDI Outputs
• Supported Resolution up to 1080i60
• No Power Connection Needed
• Complimentary ez-CGER CG software for Windows OS
• User friendly interface
• Insert texts, images, sequences, videos, and widgets
• Mini converter type

SPECIFICATIONS

Parameter
Overview	CG Output through USB 3.0 (Fill&Key)
Input	Fill & Key Input : USB 3.0 x 1
Output	Fill & Key Output : SDI x 2
USB Devices	USB 3.0 Video Streamer Device : FIll & KEy Input USB 2.0 USB to Serial (Com Port) Device : Control USB 2.0 USB to SPI Device : Firmware Update
System Requirement	OS : Windows7, Windows8, Windows10 CPU: Intel i5 2.8GHz & above USB 3.0 Host Controller
Internal Video Processing	YCbCr 4:2:2 10bit
Resolution Supported	1280 x 720p @60/59.94/50 1920 x 1080i @60/59.94/50
Management	USB : Easy to use GUI application, Firmware update
Physical	Operation Temperature : 0 – 40 °C Power Consumption : 4W (max.)







INCLUDED BY DEFAULT

• Lumantek ez-CGER mini Live HD-SDI USB Fill/Key and CG Generator with CGER Software
