Lumens VC-A53 1080p PTZ IP Camera with 20x Optical Zoom (Black)

Add a fast PTZ camera to your auditorium, lecture hall, meeting room, house of worship, or production environment with the white VC-A53 1080p PTZ IP Camera with 20x Optical Zoom from Lumens. This camera features a 20x optical, up to 225°/second moves, and built-in networking with PoE (power over Ethernet), video streaming, and IP control. The camera’s 1/2.8″ 2.13MP CMOS sensor offers support for up to 1080p60 video and simultaneous 3G-SDI, HDMI, and RJ45 outputs. Using its RS-232, RS-422, IR remote, and Ethernet LAN connectivity, you can program up to 256 position presets using serial or IP control. Features include full manual and automatic modes, audio input for adding a mic or line source to your production, and an image-flip feature that allows you to mount the camera on a wall or ceiling using the included hardware. An AC adapter and IR remote control are also included.

High-Speed Robotics

High-precision motors enable the VC-A53 to both quickly move between preset positions at speeds up to 225° per second and to deliver smooth low-speed moves.

Built-In Networking

The VC-A53’s Ethernet multipurpose port supports power over Ethernet, video streaming in a variety of secure and broadcast standard formats, and IP control. Users can remotely control multiple units and manage their cameras facility-wide using the complimentary Lumens Deployment Tool 2.0.

Production Ready

Based around a professional Sony sensor, the VC-A53’s video output can easily be integrated into mixed-camera productions. This unit can be controlled using RS-232, RS-422, USB, and Ethernet control interfaces, enabling users to add the camera into existing workflows.

Intelligent Automatic Modes

The VC-A53 offers full manual settings to give producers full creative control. It also incorporates intelligent automatic modes that deliver exceptional autofocus, predictive autoexposure and auto white balance. These features enable users to trust the camera to run without user input and to deliver consistently professional results.

KEY FEATURES

• Supports up to 1080p60 Video
• 1/2.8″ 2.16MP CMOS Sensor
• 20x Optical Zoom, 57° Viewing Angle
• 5.33-110mm Zoom Lens, f/1.6-3.8 Aperture
• IP Interface with PoE+ Power and Control
• Simultaneous HDMI/IP/3G-SDI Output
• 256 Preset Positions, Audio Input
• RS-232 / RS-422 / IP / USB Control
• ONVIF, VISCA, and Protocols
• WDR, Image Flip, 3D NR & Tally Light

SPECIFICATIONS

Camera
Model	VC-A53P
Sensor	1/2.8″ 2.16MP CMOS
Video Format	1080p : 60 / 50 / 30 / 25 720p : 60 / 50 / 30
Video Output (HD) Interface	3G-SDI / HDMI / Ethernet / USB3.0
Optical Zoom	20x
Viewing Angle	57°
Aperture	F1.6~F3.8
Focal Length	5.33mm~110mm
Shutter Speed	1/1 ~ 1/10,000 sec
Minimum Object Distance	Wide: 0.5M / Tele: 1.5M
Video S/N Ratio	> 50dB
Minimum Illumination	1.0 lux (F1.6, 50IRE, 30fps)
Focus System	Auto / Manual / Smart AF
Gain Control	Auto / Manual
White Balance	Auto / Manual
Exposure Control	Auto / Manual
WDR	Yes
3D NR	Yes
Image Flip	Yes
AR / VR Systems	FreeD
Tally Light	Yes
PoE	PoE+ (IEEE802.3at)
Pan & Tilt
Panning Angle	+170° ~ -170°
Panning Speed	225°/sec
Tilting Angle	+90° ~ -30°
Tilting Speed	225°/sec
Preset Positions	256
Output
HDMI / 3G-SDI	1080p60
IP Stream	Main : H.264 1080p 60 Second : H.264 640x360p 30 Webpage Preview: 1280×720 30
IP Compression	H.264
Audio
Input	Lin-in / Mic-in
Output	Ethernet / USB 3.0 / HDMI / SDI
Camera Control
Interface	RS-232 / RS-422 / Ethernet / USB / Remote
Protocol	VISCA / VISCAIP / ONVIF
General
DC In	12V +/- 20%
Power Consumption	PoE: 10W DC In: 9W
Weight	2 kg
Dimensions (W x H x D)	174 x 186 x 187 mm

INCLUDED BY DEFAULT

• Lumens VC-A53 1080p PTZ IP Camera with 20x Optical Zoom
• Remote Control
• Power Adapter
• Power Cord
• Metal Mounting Plate A
• Metal Mounting Plate B
• 8 x Screw (Black)
• 2 x Screw (Silver)
