Magewell USB Capture DVI Plus
The Magewell USB Capture DVI Plus is a flexible external capture card that connects to your computer via USB 3.0 and supports a variety of input video formats. The Capture DVI Plus sports a built-in DVI-I input, and using the included adapters and breakout cables you can capture DVI-I, DVI + audio, VGA + audio, component video + audio, analog audio by itself, as well as HDMI video with its embedded audio.
The Capture Plus supports Windows, Mac, and Linux and may be used with select Chrome OS installations. It supports a variety of video formats with resolutions up to 2048 x 2160 and frame rates up to 120 fps. The default capture format is YUY2 4:2:2 8-bit, but the card also supports UYVY 4:2:2 8-bit as well as RGB24 and RGB32 4:4:4 8-bit.
INTERFACE
KEY FEATURES
- One-Channel HD Capture Card
- USB 3.0 Dongle
- Capture of DVI + Audio, VGA + Audio
- Capture of HDMI + Embedded Audio
- Capture of Component + Audio
- Line-In Audio Input
- Extract HDMI Embedded Audio via Line Out
- Supports Windows, Mac, and Linux
| Input Interfaces | DVI-I
|
| Output Interface | 3.5 mm audio jack
· Unbalanced Line Out |
| Host Interface | USB 3.0
· Compatible with USB 3.1 Gen 1 · Compatible with USB 2.0 |
| OS | Recommended
Windows
Linux
Mac
|
| Supported APIs | Windows
Linux
OS X/macOS
|
| Supported Software |
|
| Power Consumption | 5 V Max Current: 600 mA Max Power Consumption: ~ 3 W |
| Environment | Operating Temperature: 32 to 122°F / 0 to 50°C Storage Temperature: -4 to 158°F / -20 to 70°C Relative Humidity: 5% to 90% Non-Condensing |
| Dimensions | 10.15 x 5.68 x 1.7 cm |
INCLUDED BY DEFAULT
- Magewell USB Capture DVI Plus
- USB 3.0 Cable
- DVI to VGA Connector
- DVI-I to HDMI + Component Breakout Cable
