Osprey 260e Capture Card



Osprey 260e Capture Card

The Osprey 260e is a single channel analog capture card offering Composite BNC, Component 3-BNC, and S-Video mini-DIN selectable inputs, along with balanced XLR or unbalanced RCA stereo audio, all via a breakout cable. The S-Video input comes on BNC connectors and is converted via an included BNC to mini-DIN adapter.



Format	1 x PCIe Slots: x1, x4, x8, or x16 PCIe 1.1
Breakout Cable Connector	15-pin connector (breakout cable included)
Video Input	1 x Composite on BNC 1 x Component on 3 BNCs 1 x Y/C on 2 BNCs (BNC to mini-DIN adapter)
Video Modes	NTSC/PAL 720 x 480 29.97, 30/i (NTSC) 852 x 480, 29.97, 30/i (NTSC Wide Screen) 720 x 576 25/i (PAL) Wide Screen Signaling (WSS)
Audio Input	1 x Balanced stereo via 2 XLR connectors 1 x Unbalanced stereo via 2 RCA connectors
Audio Output	Unbalanced stereo line (3.5 mm)
Power Consumption	3.58 W
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-40 to 167°F (-40 to 75°C)
Operating Relative Humidity	5 to 80% (non-condensing)
Storage Relative Humidity	95% RH (non-condensing); gradient 30% per hour
Operating Altitude	0 to 10,000 ft (0 to 3,048 m)
Storage Altitude	0 to 50,000 ft (0 to 15,240 m)
Dimensions	L x H: 5 x 2.7″ (12.7 x 6.7 cm) Low profile/half length
Weight	2.3 oz (67 g)
