Reach Bee8+ 4K All-In-One Recording Appliance For Live Streaming And Distribution

4K All-In-One Recording Appliance for Live Streaming and Distribution

Bee8+ is a high-performance video encoder and playing based on the latest video processing chip. The device integrates high-definition video, audio, VGA, USB and other interfaces, automatically recognizes the signal source, records and generates general MP4 format video files. The system can easily realize the PC, tablet computer and other multi-point cooperative management control, can cooperate with the Reach Media Center Pro platform to carry on the Internet direct broadcast, supports the Android, iOS and other mobile terminals to share the resources.

• Capture and record 4K, up to 4K( 3840*2610@30 )
• Support synchronous signal capture, recording, live streaming and video on demand streaming
• Support up to 5 video HDMI inputs (SDI input optional)
• Support RTSP and RTMP protocol,
• Supoort for RTMP streaming to YouTube, Facebook or other service
• MP4 file format
• Integrated control button on front panel, to support one button start/stop or pause recording, download files or local playback
• Remote control by telnet or serial port, Webpage UI, Front Panel Button, Software Client, Keyboard and mouse
• Download previously recorded content
• Powerpoint push function, automatically sends presentation content from HDMI input 5 to up to 40 mobile devices, by scanning and viewing generated QR code
• Powerpoint switch function, automatically displays presentation content from HDMI input 5 for a predetermined duration, then switches back to the video
• Monitor content live and in playback from HDMI output( with audio HDMI embed audio)
• Unattended FTP/SFTP file transfer, with scheduling support
• Linux OS, dedicated hardware

Model	A5200 / Bee8+
Operation System	Linux OS
Input numbers	5 HDMI digital video or 4 SDI digital component video + 1 HDMI digital video
HDMI Input Port 1-5	Support resolution: 720p@50@60, 1080p@25@30@50@60 3840*2160@30
SDI Input Port 1-4	Support resolution: 720p@50@60, 1080p@25@30@50@60
Output numbers	2 HDMI Output
HDMI Output Port 1	1920*1080@50@60,3840*2610@30
HDMI Output Port 2	1280*720@60 1920*1080@50@60
Audio Input	Mic input: 1*Phoenix or 1*RCA Line input: 1*Phoenix or 1*3.5mm HDMI input 5 interface embedded audio input
Audio Output	Line Out: 1*Phoenix, 1*RCA
Encoding	Video: H.264 High Profile, H.265 HEVC (4K recording version) Audio: AAC
Video Format	Standard MP4
Management	Webpage UI , Front Panel Button, Software Client, Keyboard and mouse
Audio Bit Rate	128Kbps
Audio Sample Rate	48KHz
Language	English, Simplified Chinese, Traditional Chinese
Storage	2TB by default, can be upgraded to 8TB maximum
Power	DC12V, 5A, 60W
Dimensions	430mm*335mm*44.5mm (L*W*H)
Control port	6*RS232, 1* RS485
Weight	10.0Kg
Relative Humidity	5% to 95%
Working Temperature	-20℃ to 60℃
Storage Temperature	-40℃ to 80℃
