SKAARHOJ Inline 22 w/Blue Pill Inside
The Skaarhoj Inline 22 w/Blue Pill Inside has the perfect modular controller to use alone or with our other large form factor controllers. The Inline 22 has a row of 18 awesome four-way buttons with RGB coloring, 4 encoder knobs, and 22 customizable graphical OLED displays for function legends.
This product comes with Blue Pill Inside. Blue Pill Inside means that the hardware of a Blue Pill is moved into your controller instead of combining a stand-alone Blue Pill with a UniSketch panel. The net result is the same, but with some twists: The advantage of Blue Pill Inside is that at the same cost you have everything in one unit – but you can’t enjoy the features from UniSketch anymore.
Outstanding differences from previous or similar versions
More buttons than Inline 10, completely different form factor and comes with Blue Pill Inside.
KEY FEATURES
- Blue Pill Inside
- Auxiliary four-way buttons
- Backlit encoders with crisp graphical OLED displays
- RGB multi-level metering LEDs for state indication and tally
- Unisketch OS
- Ethernet with PoE (IEEE802.3at)
- Made in Denmark
SPECIFICATIONS SKAARHOJ Inline 22 w/Blue Pill Inside
| Hardware specs | |
| 4-way Buttons | 18 |
| Encoders | 4 |
| Customizable OLED screen | 16 |
| Product W x D x H (mm) | 132 x 178 x 72/80 |
| Weight (g) | 718 |
| Shipping box W x D x H (mm) | 295 x 210 x 170 |
| Shipping box Weight (g) | 1600 |
| Country of Origin | Denmark |
| In the box | 12V power supply
Micro USB cable |
| Connectivity | |
| Programming Port | Micro USB |
| Networking Port | RJ45 Ethernet |
| Power Supply | 12V |
| Recommended cables (not in the box) | LAN Cat 6 S/FTP or better |
| Operation | |
| Power Consumption | 4.2 Watt |
| Operating System | Unisketch OS |
| Universal Control | Check our website for Device Core to what can be controlled
https://www.skaarhoj.com/support/device-cores |
INCLUDED BY DEFAULT
- SKAARHOJ Inline 22 w/Blue Pill Inside
- 12V Power Supply
